1. extract plugins.
2. copy plugins into your "nopCommerce\Plugins" directory.
3. login as admin
4. reStart nopCommerce application.
5. go to admin area->configuration->Plugins
6. install Core plugin from your admin panel, then Cloud storage, then Azure, then Sync plugin

7. Create Blob Storage Account

8. Create Container for pictures and separate container for thumb images

9. Copy Azure Blob Settings

10. Insert Settings

11. Created DB backup and change Storage Provider

12. Open /Sync/Mapping page and create "Category import" task
Data Source = Xml Import
Xml File Path = \Plugins\DevPartner.Misc.Sync\Xml\XmlDataNopDevV2.xml
Xml Map Path = ROW
Import Task Name = Category import
Import Shedule Task = Once per night
nopCommerce Entity = Category

Entity Field:
Name = ./Categories
SeName = ./Categories. Click Advance Edit and choose "Conversion Type"=translite
ExtId = ./Categories

13. Create Manufacture import task
Data Source = Xml Import
Xml File Path = \Plugins\DevPartner.Misc.Sync\Xml\XmlDataNopDevV2.xml
Xml Map Path = ROW
Import Task Name = Manufacture import
Import Shedule Task = Once per night
nopCommerce Entity = Manufacture

Entity Field:
Name = ./Manufacturers
SeName = ./Manufacturers. Click Advance Edit and choose "Conversion Type"=translite
ExtId = ./Manufacturers

14. Create Product import task
Data Source = Xml Import
Xml File Path = \Plugins\DevPartner.Misc.Sync\Xml\XmlDataNopDevV2.xml
Xml Map Path = ROW
Import Task Name = Product import
Import Shedule Task = Once per night
nopCommerce Entity = Product

Entity Field:
Name = ./Name
FullDescription = ./FullDescription
Sku = ./SKU
ManufacturerPartNumber = ./ManufacturerPartNumber
StockQuantity = ./StockQuantity
DisableBuyButton = ./DisableBuyButton
Price = ./Price. Click Advance Edit and choose "Conversion Type"=RegEx. Pattern - ^[1-9]\d*(\.\d+)?
OldPrice = ./OldPrice
Published = ./Published
SeName = ./SKU. Click Advance Edit and choose "Conversion Type"=translite
ExtId = ./SKU

15. Create Product Picture Import task
Data Source = Xml Import
Xml File Path = \Plugins\DevPartner.Misc.Sync\Xml\XmlDataNopDevV2.xml
Xml Map Path = product
XSL Transporm = \Plugins\DevPartner.Misc.Sync\XsltConversion\PicturesRoger.xslt
Import Task Name = Product Picture import
Import Shedule Task = Once per night
nopCommerce Entity = ProductPicture

Entity Fields:
PictureExtId = ./@PicturePath
ProductExtId = ./@SKU

16. Create CategoryProduct Import task
Data Source = Xml Import
Xml File Path = \Plugins\DevPartner.Misc.Sync\Xml\XmlDataNopDevV2.xml
Xml Map Path = ROW
Import Task Name = CategoryProduct import
Import Shedule Task = Once per night
nopCommerce Entity = CategoryProduct

Entity Fields:
ProductExtId = ./SKU
CategoryExtId = ./Categories

17. Create ManufactureProduct Import task
Data Source = Xml Import
Xml File Path = \Plugins\DevPartner.Misc.Sync\Xml\XmlDataNopDevV2.xml
Xml Map Path = ROW
Import Task Name = ManufactureProduct import
Import Shedule Task = Once per night
nopCommerce Entity = ProductManufactures

Entity Fields:
ProductExtId = ./SKU
ManufactureExtId = ./Manufactures

We've now got most of the Workflow tables defined, but we are still missing a few things. One of those things is a definition for exactly who can perform Transitions; we're going to add SubjectToAcl att to the transition model and use nopCommerce AclRecord table for our Security
Now that we've got the Workwlow model created, we can start building models for the actual process itself. In this part, we'll design the models that will hold the different States an Entity can be in as part of a Workflow, and we'll also design the tables that show how to get from one State to another (which are called Transitions). First, though, we need a table that shows what different types of States can exist. Let's get started!
  • 1:15:15 PM
  • Saturday, October 21, 2017
Designing a Workflow Engine for nopCommerce CMS: Intro

Designing a Workflow Engine for nopCommerce CMS: Intro

Our company was developed CMS plugin to simplify process of creating new entities for nopCommerce. We are using this plugin extremely in our development process and it’s really good solution for creating new pages and templates for nopCommerce. Also we started to use it for implementing Business logic and noticed that a lot of processes were relatively similar: Our company started thinking that, since we had so many similar processes like approvals and notifications, could we build a database-driven tool to manage all of them?
